description of the product:
1、16MM cross chain with D4.5MM section, smooth driving.
2、TUV/GS and ONORM V5117 approval.
3、The cross chain is heat treated and case hardened with zinc plated. Side chain and tension chain with plastic sprayed finish.
4、Package: 1 pair per plastic box, 5 pairs per outer carton.
5、Accessories: 4 pcs of repair links and 1 pair of PVC glove.
6、Mounting the snow chain without moving vehicle.
7、Any instructions given by the vehicle manufacturer shall be observed.
| TIRE TABLE OF 4X4 | ||||||||
| number | sizes | |||||||
| KB36/113/210 | 7.00-14 | 185/80-14 | 185/75-14 | 195/70-14 | 205/65-14 | 215/60-14 | 6.40-15 | 175/80-15 |
| 185/70-15 | 195/65-15 | 175/75-16 | ||||||
| KB37/114/220 | 6.70-14 | 195/75-14 | 195/80-14 | 205/70-14 | 205/75-14 | 215/65-14 | 185/80-15 | 195/70-15 |
| 195/75-15 | 205/65-15 | 215/60-15 | 175/80-16 | 185/70-16 | 185/75-16 | 195/65-16 | 205/55-16 | |
| 215/50-16 | ||||||||
| KB38/115/225 | 7.50-14 | 205/80-14 | 215/70-14 | 235/60-14 | 6.70-15 | 195/80-15 | 205/70-15 | 215/70-15 |
| 205/75-15 | 215/65-15 | 225/60-15 | 225/70-15 | 6.00-16 | 6.40-16 | 185/80-16 | 195/75-16 | |
| 205/65-16 | 215/60-16 | 215/65-16 | 215/55-17 | |||||
| KB39/116/230 | 215/75-14 | 215/80-14 | 245/60-14 | 7.00-15 | 205/80-15 | 215/70-15 | 215/75-15 | 225/70-15 |
| G.R.78-15 | 6.50-16 | 195/80-16 | 205/70-16 | 205/75-16 | 215/65-16 | 215/70-16 | 8R16.5 | |
| 215/60-17 | 7R17.5 | 205/65-17.5 | ||||||
| KB40/117/240 | 215/75-15 | 215/80-15 | 225/75-15 | 235/70-15 | 255/60-15 | H.R.78-15 | 7.00-16 | 205/80-16 |
| 215/75-16 | 215/80-16 | 225/65-16 | 235/60-16 | 6.50-17 | 235/55-17 | 7R-19.5 | ||
| KB41/118/245 | 8.40-15 | 28/9.00-15 | 235/75-15 | 215/85-16 | 225/70-16 | 225/75-16 | 225/65-17 | 225/70-17 |
| 205/75-17.5 | 235/55-18 | |||||||
| KB41/119/247 | 7.50-15 | 30/9.50-15 | 255/70-15 | 7.00-16 | 7.50-16 | 235/70-16 | 245/70-16 | 255/65-16 |
| 235/65-17 | 8R17.5 | 215/75-17.5 | 235/60-18 | |||||
| KB45/120/250 | 265/65-15 | 265/70-15 | 275/60-15 | 235/80-16 | 245/75-16 | 245/70-16 | 255/65-16 | 245/65-17 |
| 255/60-17 | 265/55-17 | 295/45-17 | 8.5R17.5 | 225/75-17.5 | 255/55-18 | 255/50-19 | 255/55-19 | |
| KB46/121/255 | 255/75-16 | 265/70-16 | 265/65-17 | 275/55-17 | 265/60-18 | 285/45-19 | 255/55-20 | |
| KB48/122/260 | 750-16 | 235/85-16 | 8.5-17.5 | 225/75-17.5 | 7-19.5 | |||
| KB49/123/270 | 825-15 | 825-16 | 9.5-17.5 | 235/75-17.5 | 700-18 | 750-18 | 8-19.5 | 650-20 |
| 700-20 | ||||||||
