description of the product:
1、12MM cross chain with D3.5MM section.
2、The cross chain is heat treated and case hardened with zinc plated. Side chain and tension chain with plastic sprayed finish.
3、Package: 1 pair per plastic box, 5 pairs per outer carton.
4、Accessories: 4 pcs of repair links and 1 pair of PVC glove.
5、Mounting the snow chain without moving vehicle.
6、Any instructions given by the vehicle manufacturer shall be observed.
| TIRE TABLE OF PASSANGER CARS (KL) | ||||||||
| number | sizes | |||||||
| KL 10 | 5.00-10 | 145/80-10 | 4.00-12 | 120/80-12 | 125/80-12 | 150/65-315 | ||
| KL 20 | 145-12 | 130/80-12 | 135/80-12 | 140/70-12 | 145/80-12 | 155/70-12 | 165/60-12 | 135/70-13 |
| 135/80-13 | 145/65-13 | 145/70-13 | 155/60-13 | 155/65-13 | 165/55-13 | 165/60-13 | 175/50-13 | |
| 160/60-315 | 160/65-315 | 150/65-340 | 150/65-345 | |||||
| KL 30 | 155-12 | 5.60-12 | 6.00-12 | 165/70-12 | 175/70-12 | 145/80-13 | 155/70-13 | 165/65-13 |
| 175/60-13 | 185/55-13 | 135/80-14 | 145/70-14 | 155/65-14 | 165/55-14 | 165/60-14 | 175/50-14 | |
| 125/80-15 | 135/70-15 | 160/65-340 | ||||||
| KL 40 | 155/80-13 | 165/70-13 | 175/65-13 | 185/60-13 | 195/55-13 | 5.20-14 | 145/80-14 | 155/70-14 |
| 165/65-14 | 135/80-15 | 180/55-315 | 170/65-340 | 180/60-340 | 190/55-340 | 160/65-365 | ||
| KL 45 | 175/70-13 | 175/60-14 | 185/55-14 | 155/65-15 | ||||
| KL 50 | 5.60-13 | 5.90-13 | 6.00-13 | 165/80-13 | 170/80-13 | 185/65-13 | 195/60-13 | 5.60-14 |
| 155-14 | 155/80-14 | 165/70-14 | 175/65-14 | 185/60-14 | 195/50-14 | 195/55-14 | 145/80-15 | |
| 155/70-15 | 165/60-15 | 165/65-15 | 175/55-15 | 185/50-15 | 195/45-15 | 195/40-16 | 180/65-340 | |
| 190/55-340 | 170/65-365 | 190/55-365 | ||||||
| KL 60 | 6.40-13 | 175/80-13 | 185/70-13 | 195/65-13 | 205/60-13 | 6.00-14 | 165/75-14 | 165/80-14 |
| 175/70-14 | 185/65-14 | 195/60-14 | 5.60-15 | 155/80-15 | 165/70-15 | 175/60-15 | 175/65-15 | |
| 185/55-15 | 195/50-15 | 185/50-16 | 195/45-16 | 190/65-340 | 180/65-365 | 190/60-365 | ||
| KL 65 | 175/75-14 | 205/55-14 | 185/60-15 | 195/55-15 | 205/50-15 | 200/65-340 | 195/60-365 | |
| KL 70 | 195/70-13 | 205/65-13 | 185/80-13 | 6.50-14 | 185/70-14 | 195/65-14 | 175/80-14 | 175/70-15 |
| 165/80-15 | 195/50-16 | 205/45-16 | 215/40-16 | 205/40-17 | 180/65-390 | |||
| KL 80 | 205/70-13 | 185/80-13 | 185/75-14 | 185/80-14 | 175/80-14 | 205/60-14 | 215/55-14 | 195/70-14 |
| 205/65-14 | 215/60-14 | 225/55-14 | 175/80-15 | 185/65-15 | 195/60-15 | 185/70-15 | 205/55-15 | |
| 205/60-15 | 215/50-15 | 195/55-16 | 195/60-16 | 205/50-16 | 225/40-16 | 205/45-17 | 215/40-17 | |
| 210/65-365 | 200/60-365 | 210/55-365 | 200/55-390 | 220/55-365 | 190/65-390 | 200/60-390 | 210/55-390 | |
| KL 90 | 195/75-14 | 205/70-14 | 180-15 | 6.00-15 | 185/80-15 | 195/65-15 | 195/70-15 | 205/65-15 |
| 225/50-15 | 225/55-15 | 175-16 | 175/75-16 | 195/65-16 | 205/55-16 | 215/50-16 | 225/45-16 | |
| 185/60-17 | 205/50-17 | 215/45-17 | 235/40-17 | 215/40-18 | ||||
| KL 95 | 235/60-14 | 195/80-14 | 225/60-14 | 195/75-15 | 195/80-15 | 205/70-15 | 215/60-15 | 225/60-15 |
| 235/55-15 | 255/45-15 | 205/60-16 | 205/65-16 | 215/55-16 | 225/50-16 | 215/50-17 | 225/45-17 | |
| 245/40-17 | ||||||||
| KL 100 | 205/80-14 | 215/70-14 | 215/65-15 | 215/70-15 | 225/65-15 | 230/60-15 | 235/60-15 | 215/60-16 |
| 225/55-16 | 235/50-16 | 245/45-16 | 225/50-17 | 235/45-17 | 225/40-18 | 225/45-18 | 235/40-18 | |
| 220/65-390 | 240/55-390 | 240/45-415 | ||||||
| KL 110 | 225/70-14 | 215/80-14 | 215/65-16 | 225/60-16 | 235/55-16 | 225/55-17 | 235/50-17 | 245/45-17 |
| 255/40-17 | 245/40-18 | 235/40-475 | ||||||
| KL 120 | 225/70-15 | 235/60-16 | 225/60-17 | 245/50-17 | 255/45-17 | 245/45-18 | 255/40-18 | 265/35-18 |
